Siniltruck Howo 6X4 20tons 20000liters Mobile Firefighter Water Truck
Water truck, is also called as the sprinkler, watering cart, water tank truck, water spray truck, water sprinkler truck, wanter tanker truck and multi-function green watering truck.
The water truck is mainly used in city road, large factory area, army, landscape garden and other
Departments for cleaning the pavement, sanitation, dust-proof, watering, and spraying farming
Chemicals for beautify the environment. From another point, while being urgent, the sprinkler is also
Used as the fire fighting truck.
It have self-priming and self-draining function, can flush in front, water at rear and sprinkle at the tank's
Side. It is equipped with a working platform at rear with high pressure water cannon, which can be
Columnar, heavy rainfall, moderate rain and drizzling rain, equip with high power sprinkle water pump,
Self-priming pump can pump water from pool to tank, or join the truck with fire hydrant to fill water in tank
specification
Details
Company information
Overseas Partners
Contact
To: Mr. Kaka Huang
Sales Representative
Chengli Special Automobile Co., Ltd
Factory: Chengli Automobile Industry Park,Suizhou, Hubei, China
Office: Room 3102, 7th Building, No. 299 Huaihai Road, Wuhan, China
Mobile: +86 18086020383
Water truck, is also called as the sprinkler, watering cart, water tank truck, water spray truck, water sprinkler truck, wanter tanker truck and multi-function green watering truck.
The water truck is mainly used in city road, large factory area, army, landscape garden and other
Departments for cleaning the pavement, sanitation, dust-proof, watering, and spraying farming
Chemicals for beautify the environment. From another point, while being urgent, the sprinkler is also
Used as the fire fighting truck.
It have self-priming and self-draining function, can flush in front, water at rear and sprinkle at the tank's
Side. It is equipped with a working platform at rear with high pressure water cannon, which can be
Columnar, heavy rainfall, moderate rain and drizzling rain, equip with high power sprinkle water pump,
Self-priming pump can pump water from pool to tank, or join the truck with fire hydrant to fill water in tank
specification
| Truck Model | ZZ5317M4667C | |||||
Truck Brand | SINOTRUK-HOWO | |||||
Driving Type | Left hand driving | |||||
Dimension(Lx W xH)(unloaded(mm) | 11980x2496x3700 | |||||
Carriage inner dimension(LxWxH)(mm) | 9150*2400*1500 | |||||
Approaching angle/Departure angle(°) | 19/19 | |||||
F/R track base(mm) | 2022/1830 | |||||
Tank capacity( m3 ) | 37 | |||||
Medium | Gasoline | |||||
Gear oil pump | Model | 76YCB-40(F) | ||||
flux m3/h | 40 | |||||
In /out cabiber mm | 76 | |||||
RPM r/min | 960 | |||||
Remarks:oil pump modle with F, represent relief valve, used for oil tanker truck with oil gun. | ||||||
Wheel base (mm) | 4600+1350 | |||||
Max speed(km/h) | 90 | |||||
Curb weight(kg) | 16360 | |||||
Loading Weight(kg) | 31000 | |||||
Engine (Steyr technology, made in China) | Model | WD615,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection | ||||
Fuel type | Diesel | |||||
Horse Power, max(kw/rpm) | 266HP. 290HP, 336HP | |||||
Emission | EURO II | |||||
Fuel tanker capacity(L) | 300 | |||||
Transmission | Model | HW13710CL,10 forwards and 2 reverse | ||||
Brake system | Service brake | Dual circuit compressed air brake | ||||
Parking brake | spring energy, compressed air operating on rear wheels | |||||
Auxiliary brake | Engine exhaust brake | |||||
Steering system | Model | ZF8098 | ||||
Front axle | HF7 | |||||
Rear axle | MCY13Q | |||||
Color | Optional | |||||
Tire | 11.00-20 / 12.00-20/ 295/80R22.5 | |||||
Tire quantity | 12+1 spare | |||||
Electrical system | Battery | 2X12V/165Ah | ||||
Alternator | 28V-1500kw | |||||
Starter | 7.5Kw/24V | |||||
